OEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz Waterproof

  • 1
  • 2

Brand Name : WS

Model Number : 213

Certification : ROHS,REACH,POPS

Place of Origin : CHINA

MOQ : 200-500pcs

Delivery Time : 5-7days

Supply Ability : 1,000,000pcs per month

Payment Terms : TT,PAYPAL,WU

Product Name : NFC Label

Antenna Size : customized

Reading Distance : 0---10CM

Write Endurance : 100, 000 cycles

Frequency : 13.56MHz

Antenna Material : Aluminum

Chip : 213

Price : Please contact us

Contact Now



Waterproof Plastic Round RFID 13.56mhz NFC Patrol tag sticker





Quick Details



1. Antenna Material:        Aluminum

2. Substrate Material:       PET PVC Paper

3. Antenna Thickness:     0.03mm

4. Substrate Thickness:    0.03mm

5. Frequency:                     14.0+/-0.5MHz

6. Reading Distance:         0---10CM





Chip NFC
Memory 144/504/888bytes
Antenna Aluminium etching antenna
Bonding Flip chip
Unwinding chip side up
Thickness 0.07mm
Reading   Distance 0-10cm (depends on   reader applied)
Operation   Temp. -20°C~+65°C
Storage Temp. -25°C~+65°C
Date Storage ≥10 years
Packing 10,00pcs/roll each roll in a inner case , 4 rolls per master ctn
Samples upon request
Declare

The showing picutre is only fore reference of our product.All related to   intelletural property

rights of trademark belong to trademark company





the size we have now is below.other sizes can be customized



size(mm)  size     (mm)
44x24  R2    dia 30
50X45  R3   40
60X30  R2   25
74X21  R2   28
50X50  R2
47X27  R3
109X10 R2
36X22  R2
100X14 R5
85X54  R3
55X20  R2
42x26 R2
100X100 R4
56X18
15X30
41X25
35X18
45X45
16X50
12.7X73
101X25
51x51







OEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz WaterproofOEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz WaterproofOEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz WaterproofOEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz Waterproof

Handling

  • Inlays with ink marks are defective, do not use.
  • RFID Inlays or labels are sensitive product, do not bend or stretch
  • Static-free bag will be use for packing; always keep environmental static charge to a minimum.
  • InlaySolution reserves the right to modify, change, supplement or discontinue product offerings at any time without notice
  • All products from Unico Solution should be tested by the customer/user thoroughly to ensure the product meets the particular requirements. Unico Solution does not represent that this product is fit for any particular purpose or use.





OEM 213 Chip Plastic Patrol RFID NFC Tag Sticker 13.56mhz Waterproof
